Hurst roll control

[roadrr]

getting ready to do the new brake lines on my project, 4speed car. I am looking for detailed pictures on where you installed the line lock and how you ran the lines...I know look online for instructions, I`m just looking to see what everyone has done. I have never installed one before either so any info would be great.



[Jack R]

That’s an easy install. Just follow the directions that come with the hurst kit. I’ve had that one in my bow tie car with a lot of use and still works great.



[torredcuda]

Not sure if you can see it here, I`ll have to better pics later, but I made a bracket off the master cylinder.



[roadrr]

Not sure if you can see it here, I`ll have to better pics later, but I made a bracket off the master cylinder.

View attachment 36887

good idea! can you get a picture of how you ran the lines?



[torredcuda]

Line from rear of proportion valve goes to in line loc line out is t-'d to go to front brakes.
